Compressor Duty Motor, 3 Phase 2HP Electric Motor for Air Compressor, 3450 RPM, 56 Frame, 5/8" Shaft Diameter, TEFC, AC Electric Motor

SpecificationsItem Name: Electric Compressor MotorType: SHDCAC Phase(PH): 3 PhaseFrame: 56Base RPM: 3450Horsepower: 2HPAC Frequency Rating: 60 HZCurrent: ACVoltage: 208-230/460 VoltFull Load Amps: 6.3/3.0AMounting Type: Base-Mounted (Removable Base)Enclosure Type: TEFCShaft Length: 1.88" Shaft Diameter: 5/8"Additional information: Rigid Base; CL B Insulation; 40℃(104°F) Ambient TempApplication: Oilfield, agriculture and air compressorPackage Includes1 * 3 Phase Electric Motor

• 【Wide Applications】- VONZOER Air compressor motor is universal and suitable for air compressors, steel industry, construction industry, water pump industry, fan industry, household appliances, agricultural machinery and other fields.
• 【Main Parameters】- Item Name: Electric Compressor Motor; Type: SHDC; AC Phase(PH): 3 Phase; Frame: 56; Base RPM: 3450; Horsepower: 2HP; AC Frequency Rating: 60 HZ; Current: AC; Voltage: 208-230/460 Volt; Full Load Amps: 6.3/3.0A; Mounting Type: Base-Mounted (Removable Base); Enclosure Type: TEFC; Shaft Length: 1.88"; Shaft Diameter: 5/8"; Additional information: Rigid Base; CL B Insulation; 40℃(104°F) Ambient Temp
• 【Premium Material】- The electric motor is made of high-grade steel. Strong and durable materials can protect the motor well and protect the inner circuit from thermal overloading. It includes the stable mounting bracket.
• 【High Efficiency】- Compact structure and small size, the air compressor motor can run at the maximum speed 3450 RPM, high working efficiency; there are many heat dissipation holes, so that it has great heat dissipation performance.
• 【Totally Enclosed Fan】- Featured with big fan at one end, which cools the motor in long-time running, even in damp and dusty environments, reduces energy costs, reduces running temperature, increases service lifetime.
